Cable T/W 1.5mm Brown/Red 21a - CTW013-100NR

https://www.batteriesandsolar.co.uk/web/image/product.template/262469/image_1920?unique=397052e
High-performance, modern automotive cable designed for use in 12V and 24V systems. With a 21A current rating and thinwall construction, this cable is ideal for vehicle wiring harnesses, offering a lightweight, space-saving alternative to traditional BS6862 PVC cables.

£ 0.40 0.4 GBP £ 0.40 VAT Included

£ 0.33 VAT Included

  • ​Amps Range
  • ​Brand (old)
  • Cable Diameter
  • Cable Sheath Type
  • Current (Amps) (A)
  • Number of Cores

This combination does not exist.

Found it cheaper? We offer a Nationwide Price Promise on all products.

Contact Us
​Amps Range: 20-29A
​Brand (old): Batteries & Solar
Cable Diameter: 1.5mm (15AWG)
Cable Sheath Type: Thinwall
Current (Amps) (A): 21.0
Number of Cores: Single Core

Terms and Conditions

Internal Reference: 104464

Engineered for post-1995 vehicles, this 1.5mm² cable features a plain copper conductor and hard-grade, lead-free PVC insulation, conforming to ISO 6722 Class B. Its thinwall design delivers up to 30% less volume, enabling tighter cable runs and reduced vehicle weight. Commonly used by OEMs, it is suitable for both automotive and light industrial applications and offers resistance to petrol, lubricating oils, and diluted acids.

IMPORTANT NOTICE:

Please note that the images of the product shown above are for illustrative purposes only.

While we strive to provide accurate representations, there might be slight differences between the product image and the actual product you receive. These variations could be due to lighting, individual screen settings, product enhancements, or minor design updates from the manufacturer.

We assure you that any discrepancies are minimal and will not affect the overall quality and functionality of the product.

If you have any questions or concerns, please feel free to contact our customer support team for further assistance at support@batsol.co.uk or phone us at 01752 656270.

At Batteries and Solar, your satisfaction is our top priority, and we are committed to providing the best shopping experience for you.

Thank you for choosing Batteries and Solar for your purchase.

  • 1.5mm² twin colour cable (brown/red stripe)
  • Rated to 21A – suitable for 12V and 24V systems (up to 60V max)
  • Thinwall construction saves space and weight – up to 30% less volume
  • Hard-grade, lead-free thermoplastic PVC insulation
  • Plain copper conductor – high conductivity, easy to terminate
  • Temperature range: -40°C to +105°C (short-term up to +120°C)
  • Excellent chemical resistance – suitable for automotive fluids
  • Used by leading OEMs for wiring harnesses and systems

SpecificationDetails
Product NameCable T/W 1.5mm Brown/Red 21A
Product CodeCTW013-100NR
Conductor Area1.5mm²
Current Rating21 Amps
Cable TypeThinwall Automotive Cable
Insulation MaterialHard Grade PVC – Lead Free
Conductor MaterialPlain Copper (C-EPT1)
Standards ComplianceISO 6722 Class B, EN 13602, ISO 6722/LV112 Type B
Voltage Range12V / 24V systems (maximum 60V)
Temperature Range-40°C to +105°C (excursions to +120°C)
Chemical ResistanceResistant to petrol, oils, diluted acids
ColourBrown with Red stripe
ApplicationAutomotive wiring harnesses, control circuits, power lines
